uPVC Sliding Doors HST 85 mm

Description

HST 85 mm

The ideal solution for those who want a comfortable connection between the interior and the terrace and a panoramic view achieved with a large glazed area. Thanks to the modular character of the structure, there is a possibility of three arbitrary product configurations, depending on the expected thermal parameters: Basic, Standard and Premium.

HST 85 mm system is available with a low level threshold (50 mm) as standard. It is enough to lift and move the movable sash of the HST window so that both floor levels – external and internal – form one plane. Thanks to this, the space becomes open and elegant. A low level threshold guarantees effective thermal insulation, trouble-free movement for people with disabilities and small children and trouble-free maintenance thanks to removable profiles. It also allows for trouble-free modernisation of lift and slide doors.

On request, there is an additional option available: a 50 mm level threshold with a linear drainage. It is an additional gutter placed on the outer side of the sliding system, that helps to effectively drain even large amounts of rainwater and get rid of accumulated impurities, such as: leaves, sticks or small twigs.

HST 85 mm – benefits

Window frame installation depth and threshold: 197.5 mm
Maximum sash dimensions: 3000 mm x 2700 mm
Depth of the frame: 140 mm
Fittings – lift & slide system up to 180 kg
Special window fittings ensuring that the sashes move freely and without any resistance against each other or against unopened parts of the structure
A special arrangement of overlapping strikers equipped with a system of butt joint gaskets for the adequate tightness of the space between the moving sashes of HST doors
A low level threshold of 50 mm as standard
Three different threshold solutions: Basic (Alu / PVC), Standard (Alu / PVC with thermal break) and Premium (Plastic GFK, filled with foam)
More freedom in disposing of the living space – the doors do not enter deep into the room after opening
The possibility of using energy-saving glazing units with a width of up to 51 mm allows to achieve very high thermal insulation of the structure
HST 85 mm FIXFRAME – a new solution with a very narrow frame in the solid part (FIX) for the greater amount of light coming in

Additional information

Color	AP 102, AP 103, AP 104, AP 105, AP 107, AP 108, AP 109, AP 11, AP 110, AP 111, AP 112, AP 113, AP 115, AP 116, AP 19, AP 20, AP 21, AP 22, AP 25, AP 47, AP 60, AP 61, AP 62, AP 65, AP 75, AP 79, AP 94, AP-01, AP-02, AP-05, AP-06, AP-106, AP-15, AP-23, AP-27, AP-28, AP-29, AP-30, AP-32, AP-34, AP-40, AP-41, AP-43, AP-44, AP-50, AP-52, AP-63, AP-70, AP-71, AP-72, AP-88, AP-95
Brand	Aluplast
Depth of the frame [mm]	197.5
Profile thickness	Class A
Wind resistance	B3
Water resistance	7A
Acoustic insulation	33 – 45 dB
Air permeability	Class 4
